Implements a Neumann (flux) boundary condition for thermal conduction. More...

#include <VertexCFD_BCStrategy_ConductionBoundaryFlux.hpp>

Inheritance diagram for VertexCFD::BoundaryCondition::ConductionBoundaryFlux< EvalType, NumSpaceDim >:

[legend]

Collaboration diagram for VertexCFD::BoundaryCondition::ConductionBoundaryFlux< EvalType, NumSpaceDim >:

[legend]

Public Member Functions
	ConductionBoundaryFlux (const panzer::BC &bc, const Teuchos::RCP< panzer::GlobalData > &global_data)
	Constructor. More...

void	setup (const panzer::PhysicsBlock &side_pb, const Teuchos::ParameterList &user_data) override
	Set up the evaluator using side physics block information. More...

void	buildAndRegisterEvaluators (PHX::FieldManager< panzer::Traits > &fm, const panzer::PhysicsBlock &side_pb, const panzer::ClosureModelFactory_TemplateManager< panzer::Traits > &factory, const Teuchos::ParameterList &models, const Teuchos::ParameterList &user_data) const override
	Build and register field evaluators for the conduction flux. More...

void	buildAndRegisterScatterEvaluators (PHX::FieldManager< panzer::Traits > &fm, const panzer::PhysicsBlock &side_pb, const panzer::LinearObjFactory< panzer::Traits > &lof, const Teuchos::ParameterList &user_data) const override
	Build and register scatter evaluators for the boundary flux. More...

void	buildAndRegisterGatherAndOrientationEvaluators (PHX::FieldManager< panzer::Traits > &fm, const panzer::PhysicsBlock &side_pb, const panzer::LinearObjFactory< panzer::Traits > &lof, const Teuchos::ParameterList &user_data) const override
	Build and register gather and orientation evaluators. More...

void	postRegistrationSetup (typename panzer::Traits::SetupData d, PHX::FieldManager< panzer::Traits > &vm) override
	Perform post‑registration setup. More...

void	evaluateFields (typename panzer::Traits::EvalData d) override
	Evaluate the conduction flux on the side set. More...

Public Member Functions inherited from VertexCFD::BoundaryCondition::BoundaryFluxBase< EvalType, NumSpaceDim >
	BoundaryFluxBase (const panzer::BC &bc, const Teuchos::RCP< panzer::GlobalData > &global_data)

void	initialize (const panzer::PhysicsBlock &side_pb, std::unordered_map< std::string, std::string > &dof_eq_map)

void	getModelID (const Teuchos::ParameterList &bc_params, const panzer::PhysicsBlock &side_pb, std::string &model_id, Teuchos::ParameterList &side_pb_list) const

auto	getBasisIRLayout (const panzer::PhysicsBlock &side_pb, const std::string &dof_name) const

void	registerDOFsGradient (PHX::FieldManager< panzer::Traits > &fm, const panzer::PhysicsBlock &side_pb, const std::string &dof_name) const

void	registerSideNormals (PHX::FieldManager< panzer::Traits > &fm, const panzer::PhysicsBlock &side_pb) const

void	registerConvectionTypeFluxOperator (std::pair< const std::string, std::string > dof_eq_pair, std::unordered_map< std::string, std::vector< std::string >> &eq_vct_map, const std::string &closure_name, PHX::FieldManager< panzer::Traits > &fm, const panzer::PhysicsBlock &side_pb, const double &multiplier) const

void	registerPenaltyAndViscousGradientOperator (std::pair< const std::string, std::string > dof_eq_pair, PHX::FieldManager< panzer::Traits > &fm, const panzer::PhysicsBlock &side_pb, const Teuchos::ParameterList &bc_params) const

void	registerViscousTypeFluxOperator (std::pair< const std::string, std::string > dof_eq_pair, std::unordered_map< std::string, std::vector< std::string >> &eq_vct_map, const std::string closure_name, PHX::FieldManager< panzer::Traits > &fm, const panzer::PhysicsBlock &side_pb, const double &multiplier) const

void	registerResidual (std::pair< const std::string, std::string > dof_eq_pair, std::unordered_map< std::string, std::vector< std::string >> &eq_vct_map, PHX::FieldManager< panzer::Traits > &fm, const panzer::PhysicsBlock &side_pb) const

void	registerScatterOperator (std::pair< const std::string, std::string > dof_eq_pair, PHX::FieldManager< panzer::Traits > &fm, const panzer::PhysicsBlock &side_pb, const panzer::LinearObjFactory< panzer::Traits > &lof) const

auto	integrationRule () const

Static Public Attributes
static constexpr int	num_space_dim = NumSpaceDim
	Number of spatial dimensions (compile‑time constant).

Static Public Attributes inherited from VertexCFD::BoundaryCondition::BoundaryFluxBase< EvalType, NumSpaceDim >
static constexpr int	num_space_dim = NumSpaceDim

Additional Inherited Members
Protected Attributes inherited from VertexCFD::BoundaryCondition::BoundaryFluxBase< EvalType, NumSpaceDim >
std::string	_model_id

Teuchos::ParameterList	_side_pb_list

Teuchos::ParameterList	_bc_params

std::unordered_map< std::string, std::string >	bnd_prefix

std::unordered_map< std::string, Teuchos::RCP< panzer::PureBasis > >	_dof_basis_pair

Detailed Description

template<class EvalType, int NumSpaceDim>
class VertexCFD::BoundaryCondition::ConductionBoundaryFlux< EvalType, NumSpaceDim >

Implements a Neumann (flux) boundary condition for thermal conduction.

This class derives from BoundaryFluxBase and provides the machinery to construct, register, and evaluate the conduction flux on a side set. The implementation follows the standard Panzer/Phalanx evaluator pattern.

Template Parameters

EvalType	Evaluation type (e.g., Residual, Jacobian) used by Panzer.
NumSpaceDim	Spatial dimension of the problem (e.g., 2 or 3).

Constructor & Destructor Documentation

◆ ConductionBoundaryFlux()

template<class EvalType , int NumSpaceDim>

VertexCFD::BoundaryCondition::ConductionBoundaryFlux< EvalType, NumSpaceDim >::ConductionBoundaryFlux	(	const panzer::BC &	bc,
		const Teuchos::RCP< panzer::GlobalData > &	global_data
	)

Constructor.

Parameters

[in]	bc	Boundary condition descriptor from Panzer.
[in]	global_data	Shared global data required by Panzer evaluators.

The constructor stores the BC information and registers the required fields with the base class.

Member Function Documentation

◆ buildAndRegisterEvaluators()

template<class EvalType , int NumSpaceDim>

void VertexCFD::BoundaryCondition::ConductionBoundaryFlux< EvalType, NumSpaceDim >::buildAndRegisterEvaluators	(	PHX::FieldManager< panzer::Traits > &	fm,
		const panzer::PhysicsBlock &	side_pb,
		const panzer::ClosureModelFactory_TemplateManager< panzer::Traits > &	factory,
		const Teuchos::ParameterList &	models,
		const Teuchos::ParameterList &	user_data
	)		const

overridevirtual

Build and register field evaluators for the conduction flux.

Parameters

[in,out]	fm	Field manager to which evaluators are added.
[in]	side_pb	Physics block describing the side set.
[in]	factory	Closure model factory for constructing model evaluators.
[in]	models	Parameter list containing model specifications.
[in]	user_data	Additional user data required for evaluator construction.

The method creates evaluators for the flux, temperature gradient, and material conductivity, then registers them with fm.

Implements VertexCFD::BoundaryCondition::BoundaryFluxBase< EvalType, NumSpaceDim >.

◆ buildAndRegisterGatherAndOrientationEvaluators()

template<class EvalType , int NumSpaceDim>

void VertexCFD::BoundaryCondition::ConductionBoundaryFlux< EvalType, NumSpaceDim >::buildAndRegisterGatherAndOrientationEvaluators	(	PHX::FieldManager< panzer::Traits > &	fm,
		const panzer::PhysicsBlock &	side_pb,
		const panzer::LinearObjFactory< panzer::Traits > &	lof,
		const Teuchos::ParameterList &	user_data
	)		const

overridevirtual

Build and register gather and orientation evaluators.

Parameters

[in,out]	fm	Field manager to which gather/orientation evaluators are added.
[in]	side_pb	Physics block describing the side set.
[in]	lof	Linear object factory (required for orientation).
[in]	user_data	Additional user data.

These evaluators retrieve the solution values on the side set and apply the correct orientation for vector/tensor fields.

Implements VertexCFD::BoundaryCondition::BoundaryFluxBase< EvalType, NumSpaceDim >.

◆ buildAndRegisterScatterEvaluators()

template<class EvalType , int NumSpaceDim>

void VertexCFD::BoundaryCondition::ConductionBoundaryFlux< EvalType, NumSpaceDim >::buildAndRegisterScatterEvaluators	(	PHX::FieldManager< panzer::Traits > &	fm,
		const panzer::PhysicsBlock &	side_pb,
		const panzer::LinearObjFactory< panzer::Traits > &	lof,
		const Teuchos::ParameterList &	user_data
	)		const

overridevirtual

Build and register scatter evaluators for the boundary flux.

Parameters

[in,out]	fm	Field manager to which scatter evaluators are added.
[in]	side_pb	Physics block describing the side set.
[in]	lof	Linear object factory for constructing scatter operations.
[in]	user_data	Additional user data required for scatter evaluator construction.

Scatter evaluators write the computed flux contributions into the global linear system.

Implements VertexCFD::BoundaryCondition::BoundaryFluxBase< EvalType, NumSpaceDim >.

◆ evaluateFields()

template<class EvalType , int NumSpaceDim>

void VertexCFD::BoundaryCondition::ConductionBoundaryFlux< EvalType, NumSpaceDim >::evaluateFields ( typename panzer::Traits::EvalData d )

overridevirtual

Evaluate the conduction flux on the side set.

Parameters

[in] d Evaluation data containing the workset and solution fields.

The method computes the flux based on temperature gradients and material conductivity and stores the result in the evaluated field.

Implements VertexCFD::BoundaryCondition::BoundaryFluxBase< EvalType, NumSpaceDim >.

◆ postRegistrationSetup()

template<class EvalType , int NumSpaceDim>

void VertexCFD::BoundaryCondition::ConductionBoundaryFlux< EvalType, NumSpaceDim >::postRegistrationSetup	(	typename panzer::Traits::SetupData	d,
		PHX::FieldManager< panzer::Traits > &	vm
	)

overridevirtual

Perform post‑registration setup.

Parameters

[in]	d	Setup data provided by Panzer (unused in this class).
[in]	vm	Field manager (unused in this class).

This hook is required by the Phalanx evaluator interface but does not perform any actions for the conduction flux.

Implements VertexCFD::BoundaryCondition::BoundaryFluxBase< EvalType, NumSpaceDim >.

◆ setup()

template<class EvalType , int NumSpaceDim>

void VertexCFD::BoundaryCondition::ConductionBoundaryFlux< EvalType, NumSpaceDim >::setup	(	const panzer::PhysicsBlock &	side_pb,
		const Teuchos::ParameterList &	user_data
	)

overridevirtual

Set up the evaluator using side physics block information.

Parameters

[in]	side_pb	Physics block describing the side set.
[in]	user_data	User‑provided parameter list (e.g., material data).

This method extracts required data from the physics block and stores any internal mappings needed for later evaluator construction.

Parameters

user_data user_data*

Implements VertexCFD::BoundaryCondition::BoundaryFluxBase< EvalType, NumSpaceDim >.

The documentation for this class was generated from the following files:

src/conduction/boundary_conditions/VertexCFD_BCStrategy_ConductionBoundaryFlux.hpp
src/conduction/boundary_conditions/VertexCFD_BCStrategy_ConductionBoundaryFlux_impl.hpp
